RFSTI-11B-SL | Switching units with external temperature sensor

• The temperature element measures the temperature with an external sensor and at the same time controls the heating circuit (electric underfloor heating, air conditioning, boiler…).
• They can be combined with Detectors, Controllers or iNELS RF Control system components.
• It measures the temperature in the range -20 to +50 °C and sends it to the system component in a regular 5 min. intervals. It sends a signal when the temperature changes suddenly.
• The heating/cooling, hysteresis and off-set functions are set in the system component or application.
• It allows the connection of a switched load up to 8 A (2,000 W).
• Range up to 200 m (outdoors), in case of insufficient signal between the controller and the device, use the RFRP-20 signal repeater or component with the RFIO2 protocol that supports this function.
• Communication with bidirectional RFIO2 protocol.
• The BOX version offers installation directly in the installation box, ceiling, or cover of the controlled appliance. Easy installation thanks to screwless terminals.
• External sensor TC (-20 to +80 °C) or TZ (-40 to +125 °C) with a length of 3 m, 6 m, 12 m.

More information

• Supply voltage: 230 V AC / 50-60 Hz
• RF command from the transmitter: 866 - 922 MHz
• Range in open space: up to 200 m
• Working position: any
• Mounting: free at lead-in wires
• Protection: IP30
• Dimensions: 43 x 44 x 22 mm
• Weight: 31 g
